Kennametal KENN 1881423
Kennametal 1881423 Kendex Turning Insert, ANSI Code: TNG331T0820 KY1615, TNG Insert, Material Grade: C4/C8, 160404 Insert, Triangular Shape, Negative Rake, Neutral Cutting, For Use On Cast Iron, Ceramic, Manufacturers Grade: KY1615
Invoice description:
Tng331 T0820 Ky1615 B36141
Pack Size: 10
UNSPSC:
23242105
Manufacturer PN: 1881423
$17.88 EA
Factory OrderEstimated to ship in 14 days
Kennametal Turning Insert, Series: Kendex, TNG Insert, 160404 Insert, Triangular, 1.25 mm Maximum Depth of Cut, 9.53 mm Inscribed Circle, 4.76 mm Thickness, 16.5 mm Length, Negative Rake, T02020 Chipbreaker, 0.4 mm Corner Radius, Manufacturers Grade: KY1615, ANSI Code: TNG331T0820 KY1615, ISO Code: TNGN160404T02020 KY1615, 60 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Ceramic, Uncoated, Material Grade: C4/C8, For Use On: Cast Iron
Specifications
ANSI CodeTNG331T0820 KY1615
ChipbreakerT02020
Corner Radius0.4 mm
Cutting DirectionNeutral
FinishUncoated
For Use OnCast Iron
Included Angle60 deg
Inscribed Circle9.53 mm
Insert Size160404
Insert StyleTNG
ISO CodeTNGN160404T02020 KY1615
Length16.5 mm
Manufacturers GradeKY1615
MaterialCeramic
Material GradeC4/C8
Maximum Depth of Cut1.25 mm
RakeNegative
Relief Angle0 deg
SeriesKendex
ShapeTriangular
Thickness4.76 mm
