Iscar ISCAR 5502940
Iscar 5502940 DRDRILLS Single Sided Indexable Drill Insert, Special Parallelogram Shape, Material Grade: C2, C3, C5, C6, 60204 Insert, XOMT Insert, 2.56 mm THK, 6.16 mm Inscribed Circle, For Use On Alloy Steels and Stainless Steel
Invoice description:
Xomt 060204-dt Ic328
Factory Order
Iscar Indexable Drill Insert, Single Sided, Series: DRDRILLS, XOMT Insert, 60204 Insert, Special Parallelogram, 6.16 mm Inscribed Circle, 2.56 mm Thickness, DT Chipbreaker, 0.4 mm Corner Radius, Manufacturers Grade: IC328, 85 deg Included Angle, ISO Code: XOMT 60204-DT IC328, Alloy Steels and Stainless Steel For Use On, Carbide, PVD-TiCN Coated, Material Grade: C2, C3, C5, C6
Features
- Grade IC328 - a thin PVD-coated TiCN layer on a tough substrate, for milling, parting and grooving on stainless and alloy steels at low-to medium cutting speeds and for unstable machining conditions
Specifications
ApplicationFor DR drills and A-SXFOR/L boring bars
ChipbreakerDT
Corner Radius0.4 mm
FinishPVD-TiCN Coated
For Use OnAlloy Steels and Stainless Steel
Included Angle85 deg
Inscribed Circle6.16 mm
Insert Size60204
Insert StyleXOMT
ISO CodeXOMT 60204-DT IC328
Manufacturers GradeIC328
MaterialCarbide
Material GradeC2, C3, C5, C6
SeriesDRDRILLS
ShapeSpecial Parallelogram
Thickness2.56 mm
TypeSingle Sided
