SGS SGS 70533
SGS 70533 7MB Ball Nose End High Performance Metric High Performance End Mill, 6 mm Dia Cutter, 25 mm Length of Cut, 4 Flutes, 6 mm Dia Shank, 75 mm OAL, TX Coated
Invoice description:
End Mill Ball 6mm 6mm X 25mm X 75mm
UPC: 691781705330
UNSPSC:
23242511
Manufacturer PN: 70533
$56.04 EA
Factory OrderEstimated to ship in 14 days
SGS High Performance End Mill, Ball Nose End High Performance Metric, Series: 7MB, 6 mm Cutter Dia, 75 mm Overall Length, 25 mm Length of Cut, 4 Flutes, Spiral Flute, 6 mm Shank Dia, Right Hand Cutting, 38 deg Helix Angle, Straight Shank, 1.966 in Shank Length, Micrograin Solid Carbide, TX Coated
Features
- Variable pitch allows for improved chatter suppression along with improved surface finish and enhanced tool life
- Raised land and increased core diameter designed to enhance tool life and decrease tool deflection
- Ball nose design ideal for finishing operations in complex workpieces
- Recommended for materials 45 HRc (420 Bhn)
Specifications
ApplicationAerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
Cutter Diameter6 mm
Cutting DirectionRight Hand
FinishTX Coated
Flute TypeSpiral
Helix Angle38 deg
Length of Cut25 mm
MaterialMicrograin Solid Carbide
Number of Flutes4
Overall Length75 mm
Series7MB
Shank Diameter6 mm
Shank Length1.966 in
Shank TypeStraight
TypeBall Nose End High Performance Metric
Additional Information
Country of OriginUS
