SGS SGS 02562
SGS 02562 M4B Ball Nose End Fractional Micro End Mill, 0.08 in Dia Cutter, 0.12 in Length of Cut, 4 Flutes, 1/8 in Dia Shank, 1-1/2 in OAL, TA Coated
Invoice description:
.080 X 1/8 X .120 Lof X 5" Oal 4fl Stub Carb E
UPC: 691781025629
UNSPSC:
27112803
Manufacturer PN: 02562
$31.56 EA
Factory OrderEstimated to ship in 14 days
SGS End Mill, Ball Nose End Fractional Micro, Series: M4B, 0.08 in Cutter Dia, 1-1/2 in Overall Length, 0.12 in Length of Cut, 4 Flutes, Spiral Flute, 1/8 in Shank Dia, Right Hand Cutting, 30 deg Helix Angle, Common Shank, 1.38 in Shank Length, Solid Carbide, TA Coated
Features
- Four flute design allows for higher feed rates and decreased deflection, improving productivity and surface finish
- Proprietary coating allows for superior chip flow, driving industry leading productivity and value, even at low spindle speeds
- High performance carbide substrate designed specifically for micro tool applications
- Broad portfolio, offering consistent lengths of cut, to ensure application demands are met
- Advanced geometries that extend tool life, reduce chatter, cut cycle times, and improve part quality
Specifications
Cutter Diameter0.08 in
Cutting DirectionRight Hand
FinishTA Coated
Flute TypeSpiral
Helix Angle30 deg
Length of Cut0.12 in
MaterialSolid Carbide
Number of Flutes4
Overall Length1-1/2 in
SeriesM4B
Shank Diameter1/8 in
Shank Length1.38 in
Shank TypeCommon
TypeBall Nose End Fractional Micro
Additional Information
Country of OriginUS
