SGS SGS 02829
SGS 02829 M2BM Ball Nose End Metric Micro End Mill, 1 mm Dia Cutter, 3 mm Length of Cut, 2 Flutes, 3 mm Dia Shank, 38 mm OAL, TA Coated
Factory Order
SGS End Mill, Ball Nose End Metric Micro, Series: M2BM, 1 mm Diameter Cutter, 38 mm Overall Length, 3 mm Length of Cut, 2 Flutes, Spiral Flute, 3 mm Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Common Shank, 1.3779 in Shank Length, Solid Carbide, TA Coated
Features
- Two flute design is ideal for softer alloyed, non-ferrous material applications that require slotting or involve heavy chip loads
- Proprietary coating allows for superior chip flow, driving industry leading productivity and value, even at low spindle speeds
- High performance carbide substrate designed specifically for micro tool applications
- Broad portfolio, offering consistent lengths of cut, to ensure application demands are met
- Advanced geometries that extend tool life, reduce chatter, cut cycle times, and improve part quality
Specifications
Cutter Diameter1 mm
Cutting DirectionRight Hand
FinishTA Coated
Flute TypeSpiral
Helix Angle30 deg
Length of Cut3 mm
MaterialSolid Carbide
Number of Flutes2
Overall Length38 mm
SeriesM2BM
Shank Diameter3 mm
Shank Length1.3779 in
Shank TypeCommon
TypeBall Nose End Metric Micro
