SGS SGS 36591
SGS 36591 Z1B Ball Nose End Fractional High Performance High Performance End Mill, 1/2 in Dia Cutter, 1-1/4 in Length of Cut, 4 Flutes, 1/2 in Dia Shank, 3-1/4 in OAL, TA Coated
Invoice description:
1/2 Dia, 1-1/4 Loc Z Carb Ball
UPC: 691781365916
UNSPSC:
23242511
Manufacturer PN: 36591
$149.96 EA
Factory OrderEstimated to ship in 7 days
SGS High Performance End Mill, Ball Nose End Fractional High Performance, Series: Z1B, 1/2 in Diameter Cutter, 3-1/4 in Overall Length, 1-1/4 in Length of Cut, 4 Flutes, Spiral Flute, 1/2 in Shank Diameter, Right Hand Cutting Direction, 35 to 38 deg Helix Angle, Straight Shank, 2 in Shank Length, Micrograin Solid Carbide, TA Coated
Features
- Unequal helix design aids in damaging harmonics by changing the angle at which each cutting edge enters and exits the material
- Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics
- Optimal material removal rates through increased feed and depths of cut
- Ball nose design ideal for finishing operations in complex workpieces
- Recommended for materials 45 HRc (420 Bhn)
Specifications
ApplicationAerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
Cutter Diameter1/2 in
Cutting DirectionRight Hand
FinishTA Coated
Flute TypeSpiral
Helix Angle35 to 38 deg
Length of Cut1-1/4 in
MaterialMicrograin Solid Carbide
Number of Flutes4
Overall Length3-1/4 in
SeriesZ1B
Shank Diameter1/2 in
Shank Length2 in
Shank TypeStraight
TypeBall Nose End Fractional High Performance
Additional Information
Country of OriginUS
