Iscar ISCAR 6403478
Iscar 6403478 CUT-GRIP Double End Threading Insert, TIPI Insert, Rectangle Shape, 14 TPI, Internal Thread, 60 deg Partial Profile Thread, 1.8 mm Pitch, Manufacturers Grade: IC908, Material Grade: H, K, M, P, S
Invoice description:
Tipi 3.4mt-0.10 Ic908
Factory Order
Iscar Threading Insert, Double End, Series: CUT-GRIP, TIPI Insert, 3.4 Insert, Rectangle Shape, Internal Thread, 60 deg Partial Profile Thread Standard, 1.8 mm Pitch, 14 Threads per Inch, 3.4 mm Thickness, 15.7 mm Length, ISO Code: TIPI 3.4MT-0.10 IC908, 0.1 mm Corner Radius, 60 deg Included Angle, Manufacturers Grade: IC908, Carbide, PVD-TiAlN Coated, Material Grade: H, K, M, P, S
Specifications
ApplicationInternal Threading
Corner Radius0.1 mm
FinishPVD-TiAlN Coated
Included Angle60 deg
Insert Size3.4
Insert StyleTIPI
ISO CodeTIPI 3.4MT-0.10 IC908
Length15.7 mm
Manufacturers GradeIC908
MaterialCarbide
Material GradeH, K, M, P, S
Pitch1.8 mm
SeriesCUT-GRIP
ShapeRectangle
Thickness3.4 mm
Thread Standard60 deg Partial Profile
Thread TypeInternal
Threads per Inch14
TypeDouble End
Additional Information
Country of OriginIS
