Kennametal KENN 5655172

Kennametal 5655172 Milling Insert, ANSI Code: XDLT090412ERD411 X500, XDLT Insert, 090412 Insert, Carbide, Manufacturers Grade: X500, 85 deg Parallelogram Shape

Pack Size: 10
UNSPSC: 23291601
Manufacturer PN: 5655172
$24.88 EA
Factory Order
Estimated to ship in 14 days
QTY:


Kennametal Milling Insert, XDLT Insert, 090412 Insert, 85 deg Parallelogram, 3/8 in Inscribed Circle, 0.187 in Thickness, 3/8 in Width, 3/8 in Length, 0.047 in Corner Radius, 75 deg Lead Angle, Manufacturers Grade: X500, ANSI Code: XDLT090412ERD411 X500, ISO Code: XDLT090412ERD411 X500, Right Hand, Carbide, TiN+TiC Coated, Steel, Stainless Steel and High Temperature Alloys Material Application

  • Features

  • Geometry similar to D41, but with higher corner nose protection for heavier applications

Specifications

ANSI CodeXDLT090412ERD411 X500
Corner Radius0.047 in
FinishTiN+TiC Coated
Hand of InsertRight
Inscribed Circle3/8 in
Insert Size090412
Insert StyleXDLT
ISO CodeXDLT090412ERD411 X500
Lead Angle75 deg
Length3/8 in
Manufacturers GradeX500
MaterialCarbide
Material ApplicationSteel, Stainless Steel and High Temperature Alloys
Shape85 deg Parallelogram
Thickness0.187 in
Width3/8 in
