Starrett LSS 445BZ-6RL

Starrett 445BZ-6RL Mechanical Depth Micrometer, 0 to 6 in, Graduations: 0.001 in, Satin Chrome

Invoice description: Micrometer Depth Gages N O. 445445m Series 0-

UPC: 049659522242

UNSPSC: 41111601

Manufacturer PN: 445BZ-6RL

^$684.90 EA

Factory Order
Estimated to ship in 14 days

enlarge

Product Overview

Starrett Depth Micrometer, Mechanical, Series: 445, 0 to 6 in, +/-0.0001 in Mic Head, +/-0.0002 in Rods Accuracy, Graduations: 0.001 in, Flat Anvil, Flat Spindle, Ratchet Thimble, Satin Chrome

Features
The depths of holes, slots, shoulders and projections can be measured with these fine tools
4 in (100 mm) base and 5/32 in (4 mm) diameter measuring rods
Combination ratchet and speeder for uniform pressure and quicker adjustment
Ring-type knurled lock nut for quick and sure locking
Satin chrome reading surface is glare free and resists rust

Specifications

Accuracy+/-0.0001 in Mic Head, +/-0.0002 in Rods

Anvil TypeFlat

FinishSatin Chrome

Graduations0.001 in

Measuring Range0 to 6 in

Series445

Spindle TypeFlat

Thimble TypeRatchet

TypeMechanical

Additional Information

IncludesLock Kit, 0.123 x 0.155 x 151 Pin, 0.132 x 0.156 x 0.094 x 0.012 x 2-1/2 Spring, Binder Ring, Adjusting Shell, 0.375-52 Nut, 0.291-40 SCR. Spindle, Barrel Spring, 0.291-40 SCR. Spindle, Outside Shell, Shell Cap, Ratchet Assembly, #2-64 Ratchet Nut, Cap As

Standards/ApprovalPROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP)/which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP)/which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Country of OriginUS
