Harvey Tool HARV EXP0420-C3
Harvey Tool EXP0420-C3 High Performance Miniature Drill, #58 Drill - Wire, 1.066 mm Drill - Metric, 0.042 in Drill - Decimal Inch, AlTiN
Invoice description:
Drill 1.066mm Altin
Manufacturer PN: EXP0420-C3
$94.22 EA
Factory OrderEstimated to ship in 7 days
Harvey Tool, EXP0420-C3, Miniature Drill, High Performance, Metric, #58 Drill - Wire, 1.066 mm Drill - Metric, 0.042 in Drill - Decimal Inch, 1.96 in Overall Length, 2 Flutes, Helical Flute, 0.492 in Flute Length, 3 mm Shank, Cylindrical Shank, 140 deg Point, Drill Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, AlTiN, Applicable Materials: Cast Iron/Steel/Stainless Steel
Features
- Specialized flute shape for improved chip evacuation and maximum rigidity
- AlTiN coated for improved lubricity and heat resistance
- H6 Shank Tolerance for high precision tool holders
Specifications
Applicable MaterialsCast Iron/Steel/Stainless Steel
Cutting DirectionRight Hand
Cutting Edge MaterialSolid Carbide
Drill Diameter Measurement SystemMetric
Drill Size - Decimal Inch0.042 in
Drill Size - Metric1.066 mm
Drill Size - Wire#58
FinishAlTiN
Flute Length0.492 in
Flute TypeHelical
MaterialSolid Carbide
Number of Flutes2
Overall Length1.96 in
Point Angle140 deg
Point TypeDrill
Shank Size3 mm
Shank TypeCylindrical
TypeHigh Performance
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
