Harvey Tool HARV FBD0625-C3

Harvey Tool FBD0625-C3 Flat Bottom High Performance Miniature Drill, 1.587 mm Drill - Metric, 0.0625 in Drill - Decimal Inch, AlTiN

Invoice description: Drill 1.587x10.5x3x50 C3

Manufacturer PN: FBD0625-C3

^$100.82 EACH

Factory Order
Estimated to ship in 14 days

enlarge

Product Overview

Harvey Tool, FBD0625-C3, Miniature Drill, Flat Bottom High Performance, Metric, 1.587 mm Drill - Metric, 0.0625 in Drill - Decimal Inch, 1.96 in Overall Length, 2 Flutes, Helical Flute, 0.413 in Flute Length, 3 mm Shank, Cylindrical Shank, 180 deg Point, Flat Bottom Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, AlTiN, Applicable Materials: Non-Ferrous Metal/Cast Iron/Steel/Stainless Steel

Features
Flat bottom design (no point angle and no dish) allows for drilling on irregular surfaces and reduces burrs on break through
H6 Tolerance for high precision tool holders

Specifications

ApplicationDrilling on irregular surfaces and reduces burrs on break through, Drilling on inclined and rounded surfaces, creating flat bottom holes, tilted drilling for angled holes, and drilling intersecting holes, half holes, shoulders, or thin plates

Applicable MaterialsNon-Ferrous Metal/Cast Iron/Steel/Stainless Steel

Cutting DirectionRight Hand

Cutting Edge MaterialSolid Carbide

Drill Diameter Measurement SystemMetric

Drill Size - Decimal Inch0.0625 in

Drill Size - Metric1.587 mm

FinishAlTiN

Flute Length0.413 in

Flute TypeHelical

MaterialSolid Carbide

Number of Flutes2

Overall Length1.96 in
