Power Team SPX RA204

Power Team RA204 General Purpose Single Acting Spring Return Hydraulic Cylinder, 20 ton Capacity, 2-3/8 in Dia Bore, 4-1/8 in L Stroke, 8-3/8 in H Retract, 2 in Dia Rod, 9030 psi

Invoice description: Cyl 20 Ton 41/8 Stroke E Cyl 20 Ton 41/8 Strokee

UPC: 662536216166
UNSPSC: 27121602
Manufacturer PN: RA204
$2,044.26 EA
Factory Order
Estimated to ship in 7 days
QTY:


Power Team Hydraulic Cylinder, General Purpose Single Acting Spring Return, Series: RA, 20 ton, 2-3/8 in Dia Bore, 4-1/8 in Stroke, 8-3/8 in H Retract, Base Mount, 2 in Rod Dia, 9030 psi, Aluminum Housing, Hard Coated, 3-3/4 in OD

  • Features

  • Half the weight of equal capacity steel cylinders
  • Aluminum body resists sparking in explosive environments
  • Hard coated aluminum piston rod and cylinder bore resist wear and corrosion
  • Grooved piston top helps keep the load from sliding on top of piston

Specifications

ApplicationFor jacking and other non production operations
Bore Size2-3/8 in Dia
Capacity20 ton
Dimensions3-3/4 in OD
FinishHard Coated
Housing MaterialAluminum
Mounting TypeBase
Pressure Rating9030 psi
Retract8-3/8 in H
Rod Diameter2 in
SeriesRA
Stroke Length4-1/8 in
TypeGeneral Purpose Single Acting Spring Return

Additional Information

Standards/ApprovalASME B30.1
Country of OriginUS
