SGS SGS 51753
SGS 51753 HI-PERCARB 135 High Performance Double Margin Drill, #39 Drill - Wire, 0.0995 in Drill - Decimal Inch, Straight Shank, 3XD D Cutting, 2 Flutes
Invoice description:
#39 Carb Drill 2flt 3xd
UPC: 691781517537
UNSPSC:
23241605
Manufacturer PN: 51753
$90.24 EA
Factory OrderEstimated to ship in 14 days
SGS Double Margin Drill, High Performance, Series: HI-PERCARB 135, #39 Drill - Wire, 0.0995 in Drill - Decimal Inch, 2 in Overall Length, 3XD Cutting Depth, 2 Flutes, Right Spiral Flute, 9/16 in Flute Length, 1/8 in Dia x 1-1/4 in L Shank, Straight Shank, 145 deg Point, Notched Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, Solid Carbide, AlTiN Coated, Applicable Materials: Cast Iron, High Temperature Alloy, Steel, Stainless Steel, Titanium, Non-Ferrous and Hardened Steel
Features
- High performance flute design efficiently transports chips
- Increases strength for aggressive drilling
- Ti-NAMITE-A coating improves resistance to heat and wear and enhances tool life
- Double margin design improves accuracy and surface finish
- Increases stability and rigidity
- Secondary flute improves coolant flow to the point
- Reduces friction along drill body
- Assists in fine swarf evacuation
- Specialized 145 deg notched point, self-centering eliminates the need for spot drill
- Improves chip control
Specifications
ApplicationAerospace, Medical, Power Generation, Automotive, Mold and Die, General Engineering, Castings and Foundries
Applicable MaterialsCast Iron, High Temperature Alloy, Steel, Stainless Steel, Titanium, Non-Ferrous and Hardened Steel
Cutting Depth3XD
Cutting DirectionRight Hand
Cutting Edge MaterialSolid Carbide
Drill Size - Decimal Inch0.0995 in
Drill Size - Wire#39
FinishAlTiN Coated
Flute Length9/16 in
Flute TypeRight Spiral
MaterialSolid Carbide
Number of Flutes2
Overall Length2 in
Point Angle145 deg
Point TypeNotched
SeriesHI-PERCARB 135
Shank Size1/8 in Dia x 1-1/4 in L
Shank TypeStraight
TypeHigh Performance
Additional Information
Country of OriginUS
