Iscar ISCAR 5591339
Iscar 5591339 2-Sided Turning Insert, ANSI Code: CNGG 430.5 SF IC907, CNGG Insert, Material Grade: H, K, M, N, P, S, 430.5 Insert, Rhombic Shape, 12 Seat, For Use On Stainless Steel, Steel, Cast Iron, Hardened Steel, High Temperature Alloys and Aluminum
Invoice description:
Cngg 430.5-sf Ic907 Turning Insert
Pack Size: 10
UNSPSC:
23242107
Manufacturer PN: 5591339
$19.97 EA
Factory OrderEstimated to ship in 14 days
Iscar Turning Insert, 2-Sided, CNGG Insert, 430.5 Insert, Rhombic, 2 mm Maximum Depth of Cut, 12.7 mm Inscribed Circle, 4.76 mm Thickness, 12 Seat, SF Chipbreaker, 0.2 mm Corner Radius, 0.203 in Hole Dia, Manufacturers Grade: IC907, ANSI Code: CNGG 430.5 SF IC907, ISO Code: CNGG 120402-SF IC907, 80 deg Included Angle, 0 deg Relief Angle, Carbide, PVD-TiAlN+TiN Coated, Material Grade: H, K, M, N, P, S, For Use On: Stainless Steel, Steel, Cast Iron, Hardened Steel, High Temperature Alloys and Aluminum
Features
- Controls chip flow at very low feed and depth of cut
- Excellent crater wear resistance
- IC907 grade a tough sub-micron substrate, TiAlN PVD coated
- Suitable for low-to-medium cutting speeds
- Developed for machining of heat resistant alloys, austenitic stainless steel and hard steel
Specifications
ApplicationSuper Finishing Applications
ANSI CodeCNGG 430.5 SF IC907
ChipbreakerSF
Corner Radius0.2 mm
FinishPVD-TiAlN+TiN Coated
For Use OnStainless Steel, Steel, Cast Iron, Hardened Steel, High Temperature Alloys and Aluminum
Hole Diameter0.203 in
Included Angle80 deg
Inscribed Circle12.7 mm
Insert Size430.5
Insert StyleCNGG
ISO CodeCNGG 120402-SF IC907
Manufacturers GradeIC907
MaterialCarbide
Material GradeH, K, M, N, P, S
Maximum Depth of Cut2 mm
Relief Angle0 deg
Seat Size12
ShapeRhombic
Thickness4.76 mm
Type2-Sided
Additional Information
Country of OriginIL
