Iscar ISCAR 5550201
Iscar 5550201 CHAMTURN Turning Insert, ANSI Code: CC95MT 100504-SM, CC95MT Insert, 100504 Insert, Rhombic Shape, For Use On Soft Materials and Exotic Alloys, Manufacturers Grade: IC8250
Invoice description:
Cc95mt 100504-sm Ic8250
Factory Order
Iscar Turning Insert, Series: CHAMTURN, CC95MT Insert, 100504 Insert, Rhombic, 9.52 mm Inscribed Circle, 5 mm Thickness, 0.4 mm Corner Radius, Manufacturers Grade: IC8250, ANSI Code: CC95MT 100504-SM, ISO Code: CC95MT-SM, 80 deg Included Angle, For Use On: Soft Materials and Exotic Alloys
Features
- Single sided 80 deg rhombic insert
- Used for semi-finishing and finishing on a wide range of materials including soft materials and exotic alloys (part of the CHAMELEON multifunction system)
Specifications
ApplicationISO Turning
ANSI CodeCC95MT 100504-SM
Corner Radius0.4 mm
For Use OnSoft Materials and Exotic Alloys
Included Angle80 deg
Inscribed Circle9.52 mm
Insert Size100504
Insert StyleCC95MT
ISO CodeCC95MT-SM
Manufacturers GradeIC8250
SeriesCHAMTURN
ShapeRhombic
Thickness5 mm
Additional Information
Standards/ApprovalISO 13399
