Iscar ISCAR 5510349
Iscar 5510349 HELITURN LD Turning Insert, ANSI Code: CNMX 342-M3MW, CNMX Insert, 342 Insert, Rhombic Shape, Positive Rake, Manufacturers Grade: IC6015
Invoice description:
Cnmx 342-m3mw Ic6015 Turning Inserts
Pack Size: 10
UNSPSC:
23242105
Manufacturer PN: 5510349
$12.26 EA
Factory OrderEstimated to ship in 14 days
Iscar Turning Insert, Series: HELITURN LD, CNMX Insert, 342 Insert, Rhombic, 3/8 in Inscribed Circle, 0.173 in Thickness, Positive Rake, 0.031 in Corner Radius, Manufacturers Grade: IC6015, ANSI Code: CNMX 342-M3MW, ISO Code: CNMX-M3/4MW, 80 deg Included Angle
Features
- The inserts feature a very positive radial helical cutting edge and a positive rake angle, which reduces the cutting forces
- A wiper corner design produces high surface finish even at high feed rates
- Used for heavy machining applications
Specifications
ApplicationISO Turning and Internal 80 deg Diamond 95 deg Approach
ANSI CodeCNMX 342-M3MW
Corner Radius0.031 in
Included Angle80 deg
Inscribed Circle3/8 in
Insert Size342
Insert StyleCNMX
ISO CodeCNMX-M3/4MW
Manufacturers GradeIC6015
RakePositive
SeriesHELITURN LD
ShapeRhombic
Thickness0.173 in
Additional Information
Standards/ApprovalISO 13399
