Iscar ISCAR 5509918
Iscar 5509918 HELITURN LD Turning Insert, ANSI Code: CNMX 453-M4MW, CNMX Insert, 453 Insert, Rhombic Shape, Positive Rake, Manufacturers Grade: IC6025
Invoice description:
Cnmx 453-m4mw Ic6025
Factory Order
Iscar Turning Insert, Series: HELITURN LD, CNMX Insert, 453 Insert, Rhombic, 1/2 in Inscribed Circle, 0.267 in Thickness, Positive Rake, 0.047 in Corner Radius, Manufacturers Grade: IC6025, ANSI Code: CNMX 453-M4MW, ISO Code: CNMX-M3/4MW, 80 deg Included Angle
Features
- The inserts feature a very positive radial helical cutting edge and a positive rake angle, which reduces the cutting forces
- A wiper corner design produces high surface finish even at high feed rates
- Used for heavy machining applications
Specifications
ApplicationISO Turning
ANSI CodeCNMX 453-M4MW
Corner Radius0.047 in
Included Angle80 deg
Inscribed Circle1/2 in
Insert Size453
Insert StyleCNMX
ISO CodeCNMX-M3/4MW
Manufacturers GradeIC6025
RakePositive
SeriesHELITURN LD
ShapeRhombic
Thickness0.267 in
Additional Information
Standards/ApprovalISO 13399
