Iscar ISCAR 5508285

Iscar 5508285 HELITURN LD Turning Insert, ANSI Code: CNMX 120708-M4MW, CNMX Insert, 120708 Insert, Positive Rake, Manufacturers Grade: IC807

Invoice description: Cnmx 452-m4mw Ic807

UNSPSC: 23242105
Manufacturer PN: 5508285
$15.23 EA
Factory Order
Estimated to ship in 14 days
QTY:


Iscar Turning Insert, Series: HELITURN LD, CNMX Insert, 120708 Insert, 12.7 mm Inscribed Circle, 6.78 mm Thickness, Positive Rake, 0.8 mm Corner Radius, Manufacturers Grade: IC807, ANSI Code: CNMX 120708-M4MW, ISO Code: CNMX-M3/4MW, 80 deg Included Angle

  • Features

  • The inserts feature a very positive radial helical cutting edge and a positive rake angle, which reduces the cutting forces
  • A wiper corner design produces high surface finish even at high feed rates
  • Used for heavy machining applications

Specifications

ApplicationISO Turning and Internal 80 deg Diamond Approach
ANSI CodeCNMX 120708-M4MW
Corner Radius0.8 mm
Included Angle80 deg
Inscribed Circle12.7 mm
Insert Size120708
Insert StyleCNMX
ISO CodeCNMX-M3/4MW
Manufacturers GradeIC807
RakePositive
SeriesHELITURN LD
Thickness6.78 mm

Additional Information

Standards/ApprovalISO 13399
