Edison BUSS AGX-25

Edison AGX-25 Small Dimension Fast Acting Fuse With Nickel Plated Brass End Caps, 25 A, 32 VAC, 1 kA Interrupt, Cylindrical Body

Invoice description: Fuse 1/4" X 1" Glass 5/pkg

UPC: 051712704847
Pack Size: 5
UNSPSC: 39121609
Manufacturer PN: AGX-25
$6.40 EA
Factory Order
Estimated to ship in 10 days
QTY:


Edison Fast Acting Fuse, Small Dimension, Series: AGX, Non-Indicating, 25 A, 32 VAC, 1 kA Interrupt, 4 hr, 60 min, 5 s, 2 min Response, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Glass, 1/4 in Dia x 1 in L Body

  • Features

  • Size rejects insertion of other fuse types
  • 4 hr minimum at 110%, 60 min maximum at 135%, 5 sec maximum at 200%, 2 min maximum at 200% response time
  • 1 kA at 32 VAC interrupt rating
  • 1 kA at 32 VAC interrupt rating

Specifications

ApplicationInstruments, Electronic and Small Appliance Circuits Applications
Amperage Rating25 A
Body Size1/4 in Dia x 1 in L
Body TypeCylindrical
ElementSingle
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating1 kA
MaterialGlass
Mounting TypeHolder
Response Time4 hr, 60 min, 5 s, 2 min
SeriesAGX
Terminal TypeFerrule
TypeSmall Dimension
Voltage Rating32 VAC

Additional Information

Standards/ApprovalGuide JDYX2 UL File No. E19180|UL Listed|UL 248-14
Country of OriginTW
