Power Team SPX RLS750S
Power Team RLS750S RLS Low Profile Spring Return Single-Acting Hydraulic Cylinder, 75 ton Load, 3-1/8 in H Min, 3-3/4 in H Max, 5/8 in
Invoice description:
Cyl 75 Ton 5/8 Stroke Cyl 75 Ton 5/8 Stroke
Factory Order
Power Team Hydraulic Cylinder, Low Profile Spring Return Single-Acting, Series: RLS, 75 ton Load, 3-1/8 in Minimum Height, 3-3/4 in Maximum Height, 5/8 in Piston Stroke, 6-1/2 in Base Width
Features
- Cylinder body, piston and gland nut "power tech" treated for corrosion and abrasion resistance
- Standard domed piston rod (5 to 30 ton) or swivel cap (50 to 150 ton) minimize effects of offcenter loading
- Unique heavy duty spring provides fast piston return
- Oil ports are 3/8 in NPTF
- Couplers on all cylinders, except RLS50 are angled upward for extra clearance
- Low height starting at 1.63 to 4 in
- Ideal for confined areas from 1-5/8 to 4 in clearance
- 51/64 in C bore x 9/16 in D, 17/32 in thru mounting hole
Specifications
Base Width6-1/2 in
Load Capacity75 ton
Maximum Height3-3/4 in
Minimum Height3-1/8 in
Piston Stroke5/8 in
SeriesRLS
TypeLow Profile Spring Return Single-Acting
Additional Information
IncludesModel 9796 3/8 in NPTF Female Half Coupler, Swivel Load Cap
Standards/ApprovalANSI/ASME B30.1|CE Certified
