SGS SGS 34662

SGS 34662 47 Series Fractional High Performance Regular Length Square End High Performance End Mill, 1/4 in Dia Cutter, 3/4 in Length of Cut, 2 Flutes, 1/4 in Dia Shank, 2-1/2 in OAL, TB Coated

UPC: 691781346625
UNSPSC:
Manufacturer PN: 34662
$47.84 EA
Factory Order
Estimated to ship in 14 days
QTY:


SGS High Performance End Mill, Fractional High Performance Regular Length Square End, Series: 47 Series, 1/4 in Diameter Cutter, 2-1/2 in Overall Length, 3/4 in Length of Cut, 2 Flutes, Spiral Flute, 1/4 in Shank Diameter, Right Hand Cutting Direction, 35 deg Helix Angle, Straight Shank, 1-3/4 in Shank Length, Micrograin Solid Carbide, TB Coated

  • Features

  • Circular land reduces edge aggressiveness for varied speed and feed rates
  • Two flutes effectively manage the large size and volume of chips produced during the aggressive machining process
  • Excellent balance at high speeds and aggressive plunging capability

Specifications

ApplicationAerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
Cutter Diameter1/4 in
Cutting DirectionRight Hand
FinishTB Coated
Flute TypeSpiral
Helix Angle35 deg
Length of Cut3/4 in
MaterialMicrograin Solid Carbide
Number of Flutes2
Overall Length2-1/2 in
Series47 Series
Shank Diameter1/4 in
Shank Length1-3/4 in
Shank TypeStraight
TypeFractional High Performance Regular Length Square End
