GARR GARR 28120
GARR 28120 390M Ball Nose Center Cutting End Mill, 1 in Dia Cutter, 1-1/2 in Length of Cut, 4 Flutes, 1 in Dia Shank, 4 in OAL
Invoice description:
Bem 1x1-1/2locx1x4 4fl
Factory Order
GARR End Mill, Ball Nose Center Cutting, Series: 390M, 1 in Diameter Cutter, 4 in Overall Length, 1-1/2 in Length of Cut, 4 Flutes, Helix Flute, 1 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Weldon Flat Shank, Submicron Solid Carbide
Features
- Tight tolerances for precision machining
- Excellent for keyways
- For use when matching tools are necessary
- Ball radius tolerance +0.000 to 0.001 in (+0.000 to 0.025 mm)
- N/C tolerance
Specifications
Cutter Diameter1 in
Cutting DirectionRight Hand
Flute TypeHelix
Helix Angle30 deg
Length of Cut1-1/2 in
MaterialSubmicron Solid Carbide
Number of Flutes4
Overall Length4 in
Series390M
Shank Diameter1 in
Shank TypeWeldon Flat
TypeBall Nose Center Cutting
Additional Information
Country of OriginUS
Specification Sheet
