Kennametal KENN 1849059
Kennametal 1849059 Top Notch Profiling Insert, ANSI Code: NPL51 KC5010, KCGX Insert, 51 Insert, Material Grade: C3/C4, Parallelogram Shape, Manufacturers Grade: KC5010
Invoice description:
Insert Npl 51 Kc5010
UNSPSC:
23242107
Manufacturer PN: 1849059
Factory OrderEstimated to ship in 14 days
--Price Unavailable--
Kennametal Profiling Insert, Series: Top Notch, KCGX Insert, 51 Insert, Parallelogram, 1/8 in Thickness, 1/4 in Width, 0.457 in Length, 15 Chipbreaker, ANSI Code: NPL51 KC5010, ISO Code: KCGX110304L15 KC5010, 0.4 mm Corner Radius, Manufacturers Grade: KC5010, Positive Rake, 55 deg Included Angle, 8 deg Relief Angle, Left Hand, Carbide, PVD-TiAlN Coated, Material Grade: C3/C4
Specifications
ANSI CodeNPL51 KC5010
Chipbreaker15
Corner Radius0.4 mm
FinishPVD-TiAlN Coated
Hand of InsertLeft
Included Angle55 deg
Insert Size51
Insert StyleKCGX
ISO CodeKCGX110304L15 KC5010
Length0.457 in
Manufacturers GradeKC5010
MaterialCarbide
Material GradeC3/C4
RakePositive
Relief Angle8 deg
SeriesTop Notch
ShapeParallelogram
Thickness1/8 in
Width1/4 in
