Iscar ISCAR 6004891
Iscar 6004891 TANG-GRIP Parting Insert, NMF Insert, TAG Insert, Material Grade: H, K, M, P, S, 3 mm W Cutting, Neutral Lead Angle Direction, 7 deg Relief Angle, Carbide, Manufacturers Grade: IC808, PVD Coated
Invoice description:
Tag N3mf Ic808
Factory Order
Iscar Parting Insert, Series: TANG-GRIP, TAG Insert, NMF Insert, 3 mm Cutting Width, Neutral Lead Angle Direction, 7 deg Relief Angle, Rectangle Shape, 3 mm Width, MF Chipbreaker, 0.2 mm Corner Radius, Manufacturers Grade: IC808, ISO Code: TAG N3MF IC808, 90 deg Included Angle, Neutral Hand of Insert, Carbide, PVD Coated, Material Grade: H, K, M, P, S
Features
- Basic design of the C chipformer with higher deflector and smaller t-land, most suitable in grade IC5400 for general stainless steel applications for medium-to-high feeds
- Suitable also for high alloy steel
- IC808 grade - a hard, fine grain substrate with excellent chipping resistance, combined with a new SUMO TEC TiAlN PVD coating
- Provides high wear resistance
- Recommended for a very wide range of materials
Specifications
ApplicationExternal Grooving, Internal Grooving and Groove Turning
ChipbreakerMF
Corner Radius0.2 mm
Cutting Width3 mm
FinishPVD Coated
Hand of InsertNeutral
Included Angle90 deg
Insert SizeNMF
Insert StyleTAG
ISO CodeTAG N3MF IC808
Lead Angle DirectionNeutral
Manufacturers GradeIC808
MaterialCarbide
Material GradeH, K, M, P, S
Relief Angle7 deg
SeriesTANG-GRIP
ShapeRectangle
Width3 mm
Additional Information
Country of OriginIL
