Iscar ISCAR 3311608
Iscar 3311608 SUMOCHAMIQ Exchangeable Self-Centering Drill Head, ANSI Code: HCP 0295-IQ IC908, 0.295 in Dia, PVD-TiAlN Coated, #7 Insert Seat, For Use With DCN R-3D, DCN R-5D, DCN R-8D, DCN R-1.5D and DCN A-3D Indexable Head Drill, PVD-TiAlN Coated
Factory Order
Iscar Drill Head, Exchangeable Self-Centering, Series: SUMOCHAMIQ, ANSI Code: HCP 0295-IQ IC908, 0.295 in Dia, 0.181 in Insert, #7 Insert Seat, For Use With: DCN R-3D, DCN R-5D, DCN R-8D, DCN R-1.5D and DCN A-3D Indexable Head Drill, Manufacturers Grade: IC908, Carbide, PVD-TiAlN Coated, Applicable Materials: Cast Iron, Hard Material, High Temperature Alloy, Stainless Steel and Steel
Features
- Self-centering drilling heads with a unique cutting edge profile which enables drilling up to 12XD without requiring a pilot hole operation
- A hard, fine grain substrate with excellent chipping resistance, combined with a TiAlN PVD coating
- Provides high wear and oxidation resistance
- Recommended for a very wide range of materials applications and machining conditions
Specifications
ApplicationHole Making Applications
ANSI CodeHCP 0295-IQ IC908
Applicable MaterialsCast Iron, Hard Material, High Temperature Alloy, Stainless Steel and Steel
Diameter0.295 in
FinishPVD-TiAlN Coated
Insert Seat Size#7
Insert Size0.181 in
Manufacturers GradeIC908
MaterialCarbide
SeriesSUMOCHAMIQ
Suitable For Use WithDCN R-3D, DCN R-5D, DCN R-8D, DCN R-1.5D and DCN A-3D Indexable Head Drill
TypeExchangeable Self-Centering
