Cleveland CLEV C14721
Cleveland C14721 2133 General Purpose Heavy Duty Screw Machine Drill, 7/16 in Drill - Fraction, 0.4375 in Drill - Decimal Inch, M42 HSS-Co 8, Straw/Gold Oxide
Invoice description:
7/16 X 135 Deg Colbalt Screw Mach Drill
In stock
(4)
Cleveland Screw Machine Drill, General Purpose Heavy Duty, Series: 2133, Imperial, 7/16 in Drill - Fraction, 0.4375 in Drill - Decimal Inch, 3-7/16 in Overall Length, 2-1/16 in Cutting Depth, 2 Flutes, Right Spiral Flute, 2-1/16 in Flute Length, 7/16 in Dia x 1-3/8 in L Shank, Straight Shank, 135 deg Point, Split Point, Right Hand Cutting Direction, M42 HSS-Co 8 Cutting Edge, M42 HSS-Co 8, Straw/Gold Oxide, Applicable Materials: Carbon Steel, Cast Iron, Stainless Steel and Tool Steel
Features
- Cobalt provides high heat resistance for tough applications
- Short flutes provide enhanced rigidity and drill more accurate holes
- Highly heat resistant substrate for tough to machine materials
Specifications
Applicable MaterialsCarbon Steel, Cast Iron, Stainless Steel and Tool Steel
Cutting Depth2-1/16 in
Cutting DirectionRight Hand
Cutting Edge MaterialM42 HSS-Co 8
Drill Diameter Measurement SystemImperial
Drill Size - Decimal Inch0.4375 in
Drill Size - Fraction7/16 in
FinishStraw/Gold Oxide
Flute Length2-1/16 in
Flute TypeRight Spiral
MaterialM42 HSS-Co 8
Number of Flutes2
Overall Length3-7/16 in
Point Angle135 deg
Point TypeSplit
Series2133
Shank Size7/16 in Dia x 1-3/8 in L
Shank TypeStraight
TypeGeneral Purpose Heavy Duty
Additional Information
Standards/ApprovalANSI Specified|ASME B94.11M|DIN 1897
