Power Team SPX C158C
Power Team C158C C Series General Purpose Spring-Return Single-Acting Hydraulic Cylinder, 15 ton Load, 12.69 in H Min, 20.81 in H Max, 8.13 in
Invoice description:
Cyl 15 Ton 81/8 Stroke E Cyl 15 Ton 81/8 Strokee
In stock
(1)
Power Team Hydraulic Cylinder, General Purpose Spring-Return Single-Acting, Series: C Series, 15 ton Load, 12.69 in Minimum Height, 20.81 in Maximum Height, 8.13 in Piston Stroke, 2-3/4 in Base Width
Features
- Rugged, high quality cylinder used for lifting and pressing
- Aluminum bronze bearing reduces wear caused by off-center loads
- Maximum sized springs speed piston return and increase spring life
- Solid steel cylinder body for durability
- Chrome plated piston rod resists wear and corrosion
- Wide range of accessories available to thread onto piston rod, collar, or onto cylinder base
- Base mounting holes standard on 5 through 55 ton cylinder
Specifications
ApplicationLifting and Pressing
Base Width2-3/4 in
Load Capacity15 ton
Maximum Height20.81 in
Minimum Height12.69 in
Piston Stroke8.13 in
SeriesC Series
TypeGeneral Purpose Spring-Return Single-Acting
Additional Information
IncludesModel 201362 Cylinder Load Cap, 3/8 in NPTF Female Half Coupler
Standards/ApprovalANSI/ASME B30.1|CE Certified
Line Drawing
