Power Team SPX 9005A

Power Team 9005A Hydraulic Power Portable Standard Bottle Jack, 5 ton Load, 7-7/8 in H Min, 15-3/8 in H Max, 4-3/4 in, 2-3/4 in L Screw

Invoice description: Bottle Jack 5 Ton 43/4 Stroke Bottle Jack 5 Ton 43/4stroke

UPC: 662536181181
UNSPSC: 24101612
Manufacturer PN: 9005A
$302.49 EA
Factory Order
Estimated to ship in 7 days
QTY:


Power Team Bottle Jack, Hydraulic Power Portable Standard, 5 ton Load, 7-7/8 in Minimum Height, 15-3/8 in Maximum Height, 4-3/4 in Piston Stroke, 2-3/4 in Screw Length, 3 in Base Width, 5-3/16 in Base Length

  • Features

  • Choose from this complete line of premium quality, standard bottle jacks
  • The 9110B, 9015B, 9022B and 9033B feature a beveled base which allows the jack to "follow" the load, reducing the chance of dangerous side loading
  • Many jacks feature screw extensions
  • Some jacks can be used in the vertical, angled or horizontal positions
  • Serrated or contoured saddles help stabilize the load for a safer lift

Specifications

ApplicationIndustrial Lifting and Pushing Applications
Base Length5-3/16 in
Base Width3 in
Load Capacity5 ton
Maximum Height15-3/8 in
Minimum Height7-7/8 in
Piston Stroke4-3/4 in
Screw Length2-3/4 in
TypeHydraulic Power Portable Standard

Additional Information

WarrantyLifetime
Standards/ApprovalASME B30.1
