Midland Industries MIDM 10452B
Midland Industries 10452B 90 deg Elbow, 3/8 x 1/4 in Nominal, SAE Male Flare x Male NPTF End Style, CA360 Brass, Import
Invoice description:
Elbow 3/8x1/4 M Flrxmip Bs4 Elbow 3/8x1/4 M Flrxmipbs4
Factory Order
Midland Industries Elbow, 90 deg Elbow Fitting/Connector, 3/8 x 1/4 in Nominal, SAE Male Flare x Male NPTF End Style, 0.032 in Thickness, 1000 psi Pressure, -65 to 250 deg F, CA360 Brass, 0.89 in L x 0.86 in W Dimensions, Import
Features
- Good vibration resistance, use long nut when greater vibration resistance is required
- /- 0.03 tolerance on all dimensions
- 0.64 in body
- Barstock
Specifications
ApplicationLP and Natural Gas, Flammable Liquids, Instrumentation, Refrigeration, Power Steering, Hydraulic and Pneumatic Systems, Copper, Brass, Aluminum and Steel Hydraulic Tubing That Can Be Flared
Dimensions0.89 in L x 0.86 in W
Domestic/ImportImport
End StyleSAE Male Flare x Male NPTF
Fitting/Connector Type90 deg Elbow
MaterialCA360 Brass
Nominal Size3/8 x 1/4 in
Pressure Rating1000 psi
Temperature Rating-65 to 250 deg F
Thickness0.032 in
Additional Information
Standards/ApprovalASA|ASME|MS and SAE 010302
Country of OriginUS
