Midland Industries MIDM 10107

Midland Industries 10107 Union, 5/16 in Nominal, SAE Male Flare Threaded UNF, Brass, Import

UNSPSC: 40183103
Manufacturer PN: 10107
$2.50 EA
Factory Order
Estimated to ship in 14 days
QTY:


Midland Industries Union, Fitting/Connector Type: Union, 5/16 in Nominal, SAE Male Flare Threaded UNF, 0.032 in Thickness, 1/2 in Hex, 1200 psi, -65 to 250 deg F, Brass, 1.34 in L, Import

  • Features

  • Good vibration resistance, use long nut when greater vibration resistance is required
  • /- 0.03 tolerance on all dimensions

Specifications

ApplicationLP and Natural Gas, Flammable Liquids, Instrumentation, Refrigeration, Power Steering, Hydraulic and Pneumatic Systems, Copper, Brass, Aluminum and Steel Hydraulic Tubing That Can Be Flared
Dimensions1.34 in L
Domestic/ImportImport
End StyleSAE Male Flare Threaded UNF
Fitting/Connector TypeUnion
Hex Size1/2 in
MaterialBrass
Nominal Size5/16 in
Pressure Rating1200 psi
Temperature Rating-65 to 250 deg F
Thickness0.032 in
