KYOCERA KYO 8834530
KYOCERA TWF10723 GD Series Grooving Insert, ANSI Code: GDG3020N020GS GW15, GDG Insert, 3020 Insert, Neutral Cutting, 3 mm W Cutting, Manufacturers Grade: GW15, Uncoated, Material Grade: N, S
Invoice description:
Ins Gdg3020n-020gs Gw15 Ins Gdg3020n-020gs Gw15
Factory Order
KYOCERA Grooving Insert, Series: GD Series, GDG Insert, 3020 Insert, 3 mm Cutting Width, 4.3 mm Maximum Depth of Cut, GS Chipbreaker, 0.0079 in Corner Radius, 0.187 in Thickness, 20 mm Length, Manufacturers Grade: GW15, ANSI Code: GDG3020N020GS GW15, Neutral Cutting Direction, Carbide, Uncoated, Material Grade: N, S
Features
- For light interruption and finishing-medium in (N) non-ferrous metals and (S) heat-resistant alloy
- Insert for external grooving
- Low cutting force/2-edge
- 2 cutting edges
- ISO identification symbol K carbide (equivalent to K10), tough micro-grain carbide
Specifications
ApplicationHigh Wear Resistance and Toughness for Non-ferrous Materials, and Non-metals, and Titanium Alloys
ANSI CodeGDG3020N020GS GW15
ChipbreakerGS
Corner Radius0.0079 in
Cutting DirectionNeutral
Cutting Width3 mm
FinishUncoated
Insert Size3020
Insert StyleGDG
Length20 mm
Manufacturers GradeGW15
MaterialCarbide
Material GradeN, S
Maximum Depth of Cut4.3 mm
SeriesGD Series
Thickness0.187 in
Additional Information
Country of OriginJP
