Iscar ISCAR 5531112
Iscar 5531112 SOLIDDRILL Jobber Length Drill Bit, 2.5 mm Drill - Metric, 0.0984 in Drill - Decimal Inch, 140 deg Point, Submicron Grain Solid Carbide, TiAlN Coated
Invoice description:
Scd 025-015-030 Ap6 908
Factory Order
Iscar Jobber Length Drill Bit, Series: SOLIDDRILL, Metric, 2.5 mm Drill - Metric, 0.0984 in Drill - Decimal Inch, 60 mm Overall Length, 6XD Cutting Depth, 2 Flutes, Spiral Flute, 20 mm Flute Length, 3 mm Shank, Cylindrical Shank, 140 deg Point, Standard Point, Right Hand Cutting Direction, Submicron Grain Solid Carbide Cutting Edge, No Through Coolant, Submicron Grain Solid Carbide, TiAlN Coated
Specifications
ApplicationHole Making
Cutting Depth6XD
Cutting DirectionRight Hand
Cutting Edge MaterialSubmicron Grain Solid Carbide
Drill Diameter Measurement SystemMetric
Drill Size - Decimal Inch0.0984 in
Drill Size - Metric2.5 mm
FinishTiAlN Coated
Flute Length20 mm
Flute TypeSpiral
MaterialSubmicron Grain Solid Carbide
Number of Flutes2
Overall Length60 mm
Point Angle140 deg
Point TypeStandard
SeriesSOLIDDRILL
Shank Size3 mm
Shank TypeCylindrical
Through Coolant (Yes/No)No
Additional Information
Standards/ApprovalISO 13399|DIN 6537
