Dixon DIXV GLBRC60

Dixon GLBRC60 Gauge, 0 to 60 psi, 1/4 in Connection, 2-1/2 in Dial, +/- 2-1-2 %, Glycerin Liquid Filled

UPC: 089109806188
UNSPSC: 41112412
Manufacturer PN: GLBRC60
$122.68 EA
Factory Order
Estimated to ship in 30 days
QTY:


Dixon Gauge, 0 to 60 psi, 1/4 in, 2-1/2 in Dial Diameter, +/- 2-1-2 % Accuracy, Liquid Filled: Glycerin, -4 to 140 deg F, Center Back Mount, Cast Brass Case

  • Features

  • Brass movement with highly polished bearing surfaces
  • Solid cast brass case with polished ABS cover ring
  • Do not use in connection with drinking water
  • Wash hands after handling
  • Acrylic window with membrane assembly
  • Copper alloy bourdon tube

Specifications

ApplicationPumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement
Accuracy+/- 2-1-2 %
Connection Size1/4 in
Dial Diameter2-1/2 in
Liquid FilledGlycerin
MaterialCast Brass Case
Mounting TypeCenter Back
Pressure Range0 to 60 psi
Temperature Rating-4 to 140 deg F

Documents
