Campbell CAM 6250507

Campbell 6250507 788-G Turnbuckle, Jaw/Jaw, 1/2 in Thread, 2200 lb Working, 12 in Take Up, 18-3/4 in L Close, Drop Forged Carbon Steel

Invoice description: Turnbuckle Jaw & Jaw 1/2 X 12 Galv

UPC: 020418087691
UNSPSC: 31162405
Manufacturer PN: 6250507
Factory Order
Estimated to ship in 14 days
--Price Unavailable--


Campbell Turnbuckle, Series: 788-G, Jaw/Jaw End/End, 1/2 in Thread Diameter, 2200 lb Working Load, 12 in Take Up, 18-3/4 in Close Length, Drop Forged Carbon Steel, Hot Galvanized Finish

  • Features

  • 5:1 design factor
  • Turnbuckles are designed for a static load
  • In loads where there is vibration, lock nuts (jam nuts) should be used to prevent the connection from turning or loosening
  • Jaws on sizes 1/4 in through 5/8 in have hex head bolt and nut
  • Jaws on sizes 3/4 in through 1-1/2 in have cotter key and bolt

Specifications

Closed Length18-3/4 in
End/EndJaw/Jaw
FinishHot Galvanized
MaterialDrop Forged Carbon Steel
Series788-G
Take Up12 in
Thread Diameter1/2 in
Working Load2200 lb

Additional Information

WarrantyLimited Lifetime
Standards/ApprovalASTM A153/F1145|Type 1|Grade 1|Class G
Country of OriginUS
