Union Butterfield UTD 1010361
Union Butterfield 6007647 1586 Regular Spiral Flute Tap, Right Hand Cutting, 3/8-24 Thread, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Bright, HSS
Invoice description:
1586 Bottoming Chamfer: Sp Utd 1010361 Ubc 1
Factory Order
Union Butterfield Spiral Flute Tap, Regular, Series: 1586, Measurement System: Imperial, UNF, 3/8-24, Bottoming Chamfer, 3 Flutes, HSS, Bright, Class of Fit: 3B/H3, Right Hand Cutting, 1-1/4 in Thread Length, 2-15/16 in Overall Length, 0.381 in Shank Dia, Right Hand Flute Direction, Non-Ferrous Materials Material Application
Features
- The spiral flute design effectively draws chips out of the hole
- Recommended for use when tapping blind or through holes in a variety of materials
- Excellent choice for non-ferrous applications
Specifications
ApplicationFor general purpose applications
Chamfer TypeBottoming
Class of Fit3B/H3
Cutting DirectionRight Hand
Finish/CoatingBright
Flute DirectionRight Hand
MaterialHSS
Material ApplicationNon-Ferrous Materials
Measurement SystemImperial
Number of Flutes3
Overall Length2-15/16 in
Series1586
Shank Diameter0.381 in
Thread Length1-1/4 in
Thread Size3/8-24
Thread StandardUNF
TypeRegular
Additional Information
Standards/ApprovalANSI Specified|PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov|CSA Approved
Country of OriginUS
