Dormer UTD 0216156

Dormer 5976570 E536 Dormer Straight Flute Machine Tap, Right Hand Cutting, 9/16-16 Thread, Medium Thread Limit, Bottoming Chamfer, 4 Flutes, Bright, HSS

Invoice description: E536 Hss G/t Taps Fractional Bsf

UNSPSC: 23241615

Manufacturer PN: 5976570

^$61.56 EA

Factory Order

enlarge

Product Overview

Dormer Dormer Straight Flute Machine Tap, Series: E536, Measurement System: Imperial, BSF, 9/16-16, Bottoming Chamfer, 4 Flutes, HSS, Bright, Right Hand Cutting, 25 mm Thread Length, 95 mm Overall Length, 11.2 mm Shank Dia, Alloy Steel, Aluminum Alloy, Brass, Bronze, Carbon Steel, Cast Iron, Copper, Copper Alloy, Hardened Steel, Plastic, Steel, Structural Steel and Thermosetting Plastics Material Application, Medium Thread Limit

Features
The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
A medium alloyed high speed steel that has good machinability and good performance
HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications

Specifications

ApplicationFor through or blind hole applications

Chamfer TypeBottoming

Cutting DirectionRight Hand

Finish/CoatingBright

MaterialHSS

Material ApplicationAlloy Steel, Aluminum Alloy, Brass, Bronze, Carbon Steel, Cast Iron, Copper, Copper Alloy, Hardened Steel, Plastic, Steel, Structural Steel and Thermosetting Plastics

Measurement SystemImperial

Number of Flutes4

Overall Length95 mm

SeriesE536

Shank Diameter11.2 mm

Thread Length25 mm

Thread LimitMedium

Thread Size9/16-16

Thread StandardBSF
