DeWALT DW DWS535B

DeWALT DWS535 Worm Drive Circular Saw, 7-1/4 in Dia Blade, 4800 rpm Speed, 12 VDC, 15 A

Invoice description: Saw 7-1/4" Circ Wormdriv E W/brake

UPC: 885911088206
UNSPSC: 27112709
Manufacturer PN: DWS535
$375.12 EA
Factory Order
Estimated to ship in 16 days
QTY:


DeWALT Circular Saw, Worm Drive, Bare Tool, 7-1/4 in Dia Blade, 5/8 in Arbor/Shank, 4800 rpm Speed, Bevel Capacity: 53 deg, Maximum Cut at 90 Deg 2-7/16 in, Maximum Cut at 45 Deg 1-7/8 in, Blade Side Left, 12 VDC, 15 A, Aluminum/Plastic Housing Material, Soft Handle, 8 ft Cord, 13 in L Dimensions

  • Features

  • Lightweight magnesium construction for optimum user handling, comfort and strength
  • Durable cast magnesium footplate provides a tough and solid cutting platform
  • Extra wide saw hook accepts material upto 2-1/2 in wide
  • TOUGHCORD cord protection system provides 4X better cord jerk protection
  • Bevel detents at 22.5 deg and 45 deg for fast and accurate setting to common angles
  • Top accessible spindle lock enables easier and faster blade changing
  • Dual rip ports to accept available DWS5100 12 in dual port rip guide
  • Top-accessible spindle lock enables easier and faster blade changing
  • Electric brake stops blade after trigger is released

Specifications

ApplicationWood Applications
Amperage Rating15 A
Arbor/Shank Size5/8 in
Bevel Capacity53 deg
Blade SideLeft
Blade Size7-1/4 in Dia
Cord Type8 ft
Dimensions13 in L
Handle TypeSoft
Housing MaterialAluminum/Plastic
Maximum Cut at 45 Deg1-7/8 in
Maximum Cut at 90 Deg2-7/16 in
Speed4800 rpm
Tool/KitBare Tool
TypeWorm Drive
Voltage Rating12 VDC

Additional Information

IncludesBlade Wrench
Warranty3 Years
Standards/ApprovalPROP65: Some dust created by power sanding, sawing
Country of OriginUS
