Starrett LSS 696Z

Starrett 696Z Distortion Dial/Strain Gage With Balancing Attachment, 2-3/8 to 18 in, 0 to 20 to 0 Dial Reading, 0.001 in, 1-29/64 in Dial, 3/16 in Tip

UPC: 049659529012
UNSPSC: 41111630
Manufacturer PN: 696Z
$1,251.26 EA
Factory Order
QTY:


Starrett Dial/Strain Gage, Distortion, 2-3/8 to 18 in, 0 to 20 to 0 Dial, Graduations: 0.001 in, 1-29/64 in Dial, 3/16 in Tip

  • Features

  • The dial indicator movement is approximately 5/32 in and with rods and extension, provides a range from 2-3/8 - 18 in
  • There are 10 rods and one extension furnished
  • Rods are marked to designate the approximate overall length of the gage
  • Indicator has a movable bezel to adjust the dial in relation to the hand and a non-breakable crystal
  • Designed in collaboration with Hartford steam boiler

Specifications

ApplicationFor use on all diesel engine shafts and center crankshafts on any type of engine or compressor, the gage can also be applied as a strain gage on engine frames while the engine is operating
Dial Reading0 to 20 to 0
Dial Size1-29/64 in
Graduations0.001 in
Measuring Range2-3/8 to 18 in
Tip Size3/16 in
TypeDistortion
