Irwin Unibit IRW 11105
Irwin Unibit 11105 Step Drill Bit, 5 mm Dia Min Hole, 35 mm Dia Max Hole, 13 Steps, HSS, 13 Hole Sizes, 7/16 in Shank
Invoice description:
5m 13 Hole Sizes (5 Mm - 35 Mm), 2-3 Mm Incr
Factory Order
Irwin Unibit Step Drill Bit, Metric, 5 mm Diameter Minimum Hole, 35 mm Diameter Maximum Hole, 2-1/2 in Overall Length, 13 Steps, 2 to 3 mm Step Depth, 13 Hole, 1 Flutes, 10 mm/13 mm/16 mm/19 mm/21 mm/23 mm/26 mm/29 mm/31 mm/33 mm/35 mm/5 mm/7.5 mm, 7/16 in Shank, 3-Flat Shank, Self-Starting SpeedPoint Point, HSS Cutting Edge, HSS, Bright, Applicable Materials: Aluminum, Brass, Copper, Laminates, Plastic and Stainless Steel
Features
- Single flute cutting edge for greater control through steps
- 3 flatted shank prevents slipping in drill chuck
- New speed point tip penetrates faster than previous Unibit and prevents walking
- Also available with titanium nitride coating for longer life
Specifications
ApplicationFor drilling holes into thin materials
Applicable MaterialsAluminum, Brass, Copper, Laminates, Plastic and Stainless Steel
Cutting Edge MaterialHSS
Drill Diameter Measurement SystemMetric
FinishBright
Hole Sizes Cut10 mm/13 mm/16 mm/19 mm/21 mm/23 mm/26 mm/29 mm/31 mm/33 mm/35 mm/5 mm/7.5 mm
MaterialHSS
Maximum Hole Diameter35 mm
Minimum Hole Diameter5 mm
Number of Flutes1
Number of Hole Sizes13
Number of Steps13
Overall Length2-1/2 in
Point TypeSelf-Starting SpeedPoint
Shank Size7/16 in
Shank Type3-Flat
Step Depth2 to 3 mm
Additional Information
WarrantyLimited
Country of OriginUS
