Sandvik Coromant SANC 6265890
Sandvik Coromant 6265890 T-Max P Turning Insert, ANSI Code: CNMG 643-PM 4325, CNMG Insert, Material Grade: K, P, 643 Insert, Rhombic Shape, 19 Seat, Negative Rake, Neutral Cutting, For Use On Cast Iron and Steel, Carbide, Manufacturers Grade: 4325
Invoice description:
Cnmg643 Pm 4325
Factory Order
Sandvik Coromant Turning Insert, Series: T-Max P, CNMG Insert, 643 Insert, Rhombic, 0.339 in Maximum Depth of Cut, 3/4 in Inscribed Circle, 1/4 in Thickness, 19 Seat, Negative Rake, PM Chipbreaker, 0.047 in Corner Radius, 0.312 in Hole Dia, Manufacturers Grade: 4325, ANSI Code: CNMG 643-PM 4325, ISO Code: CNMG 19 06 12-PM 4325, 80 deg Included Angle, 0 deg Relief Angle, Neutral Cutting, Carbide, CVD-TiCN+Al2O3+TiN Coated, Material Grade: K, P, For Use On: Cast Iron and Steel
Specifications
ApplicationMedium Applications
ANSI CodeCNMG 643-PM 4325
ChipbreakerPM
Corner Radius0.047 in
Cutting DirectionNeutral
FinishCVD-TiCN+Al2O3+TiN Coated
For Use OnCast Iron and Steel
Hole Diameter0.312 in
Included Angle80 deg
Inscribed Circle3/4 in
Insert Size643
Insert StyleCNMG
ISO CodeCNMG 19 06 12-PM 4325
Manufacturers Grade4325
MaterialCarbide
Material GradeK, P
Maximum Depth of Cut0.339 in
RakeNegative
Relief Angle0 deg
Seat Size19
SeriesT-Max P
ShapeRhombic
Thickness1/4 in
Additional Information
Country of OriginSE
