Harvey Tool HARV 947020
Harvey Tool 947020 Variable Helix End Mill, 0.02 in Dia Cutter, 0.03 in Length of Cut, (3) Flutes, 1/8 in Dia Shank, 2-1/2 in OAL, Uncoated
Invoice description:
Bem .02x.03x1/8x2-1/2 3fl Un .1lbs
Manufacturer PN: 947020
$101.14 EA
Factory OrderEstimated to ship in 7 days
Harvey Tool, 947020, Variable Helix End Mill, 0.02 in Diameter Cutter, 2-1/2 in Overall Length, 0.03 in Length of Cut, 3 Flutes, Upcut Flute, 1/8 in Shank Diameter, Right Hand Cutting Direction, 42 deg Helix Angle, Cylindrical Shank, Solid Carbide, Uncoated
Features
- Variable helix design (approx. 42) improves performance in off-center contour milling applications
- Reduced neck diameter to avoid heeling
- Ball end for profiling
- H6 shank tolerance for high precision tool holders
- Applicable Materials are Aluminum, Cast Iron, Steel, Stainless Steel, Wood, Composites
- Overall Reach 0.1000 in
- Reach Multiple (5x)
- Profile Ball
Specifications
ApplicationFor off-center contour milling applications
Cutter Diameter0.02 in
Cutting DirectionRight Hand
FinishUncoated
Flute TypeUpcut
Helix Angle42 deg
Length of Cut0.03 in
MaterialSolid Carbide
Number of Flutes3
Overall Length2-1/2 in
Shank Diameter1/8 in
Shank TypeCylindrical
TypeCenter Cut Stub Length Variable Helix
Additional Information
Country of OriginUS
