Harvey Tool HARV 13850
Harvey Tool 13850 Center Cut Long Length Miniature End Mill, 0.05 in Dia Cutter, 0.3 in Length of Cut, (3) Flutes, 1/8 in Dia Shank, 2-1/2 in OAL, Uncoated
Invoice description:
Bem .05x.30x1/8x2-1/2 3fl Un .60"lbs
Manufacturer PN: 13850
$80.36 EA
Factory OrderEstimated to ship in 7 days
Harvey Tool, 13850, Miniature End Mill, Center Cut Long Length, 0.05 in Diameter Cutter, 2-1/2 in Overall Length, 0.3 in Length of Cut, 3 Flutes, Upcut Flute, 1/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Cylindrical Shank, Solid Carbide, Uncoated
Features
- Long Length Design for Deep Cavities
- Long Flutes for Deep Pocket Milling
- Applicable Materials are Aluminum, Cast Iron, Steel, Stainless Steel, Wood, Composites
- Overall Reach 0.6000 in
- Reach Multiple (12x)
- Profile Ball
Specifications
ApplicationIdeal for deep cavity and deep pocket milling
Cutter Diameter0.05 in
Cutting DirectionRight Hand
FinishUncoated
Flute TypeUpcut
Helix Angle30 deg
Length of Cut0.3 in
MaterialSolid Carbide
Number of Flutes3
Overall Length2-1/2 in
Shank Diameter1/8 in
Shank TypeCylindrical
TypeCenter Cut Long Length
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
Sds
