Sandvik Coromant SANC 5742013
Sandvik Coromant 5742013 T-Max U-Lock Boring Bar, ANSI Code: R166.0KF-D10-D0812-2B, Internal Thread, Right Hand of Holder, Insert Compatibility: R166.0L-11..
Invoice description:
R166.0kf-d10-d0812-2b Tmax Laydown Thrd Bbar
Factory Order
Sandvik Coromant Boring Bar, Series: T-Max U-Lock, Internal Thread, Right Hand of Holder, 5/8 in Shank Width, 0.57 in Shank Height, 5 in Overall Length, Insert Compatibility: R166.0L-11.., 0.82 in Head Length, ANSI Code: R166.0KF-D10-D0812-2B, 0.819 in Depth of Cut, R/L166.0KF Tool Holder, 0.394 in Center to Cutting Edge, Screw Clamp Insert Holding Method, Through Coolant: No
Features
- Cost efficient solution with three cutting edges
- Three sharp cutting edges for high quality threads
Specifications
ApplicationThread Turning Applications
ANSI CodeR166.0KF-D10-D0812-2B
Center to Cutting Edge0.394 in
Depth of Cut0.819 in
Hand of HolderRight
Head Length0.82 in
Insert CompatibilityR166.0L-11..
Insert Holding MethodScrew Clamp
Overall Length5 in
SeriesT-Max U-Lock
Shank Height0.57 in
Shank Width5/8 in
Thread TypeInternal
Through Coolant (Yes/No)No
Tool Holder StyleR/L166.0KF
Additional Information
Includes5763193 Insert Screw and 5764144 Key
Country of OriginUS
