Harvey Tool HARV 35502
Harvey Tool 35502 Center Cut Stub Length Miniature End Mill, 0.109 in Dia Cutter, 0.163 in Length of Cut, (3) Flutes, 1/8 in Dia Shank, 3 in OAL, Uncoated
Invoice description:
Em 7/64x.163 1-5/16 3fl Sq Crb
Manufacturer PN: 35502
$66.66 EA
Factory OrderEstimated to ship in 14 days
Harvey Tool, 35502, Miniature End Mill, Center Cut Stub Length, 0.109 in Diameter Cutter, 3 in Overall Length, 0.163 in Length of Cut, 3 Flutes, Helical Flute, 1/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Cylindrical Shank, Solid Carbide, Uncoated
Features
- Long length design for deep cavities, up to 10 in overall length
- Stub flute for maximum rigidity
- Reduced neck diameter to avoid heeling
- Applicable Materials are Aluminum, Cast Iron, Steel, Stainless Steel, Wood, Composites
- Overall Reach 1.3120 in (1-5/16)
- Reach Multiple (12x)
- Profile Square
Specifications
Cutter Diameter0.109 in
Cutting DirectionRight Hand
FinishUncoated
Flute TypeHelical
Helix Angle30 deg
Length of Cut0.163 in
MaterialSolid Carbide
Number of Flutes3
Overall Length3 in
Shank Diameter1/8 in
Shank TypeCylindrical
TypeCenter Cut Stub Length
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
