Power Team SPX PA554

Power Team, PA554, Air Driven Pump, 2-Speed, Series: PA55, 150 ton Capacity, 55 cu-in/min Air Flow, 3/8 in NPTF Fluid Port, 525 cu-in Oil, 2.5 gal Reservoir, 40 to 120 psi Air, 11-1/2 in Length, 9-1/2 in Width, 19 in Height

• Features

• Advance/hold/return valve
• Holds when motor is shut-off and valve is in advance position
• Rotary style air motor, use where air is the preferred source of energy
• 3 hp (2.2 kW) motor starting under full load
• Two speed operation for rapid cylinder advance
• Models available with full remote control over advance and return
• Tandem center valve holds the load when pump is shut off
• High performance pump with 2-1/2 gal steel reservoir

Specifications

Additional Information

Documents

• Specification Sheet

• Instruction/installation Manual

• Line Drawing
