Armstrong JAC 30248

Armstrong Combination Wrench, Long Length Open End, Measurement System: Imperial, 1-1/2 in Wrench Opening, 12 Points, 21-1/8 in Overall Length, 15 deg Offset, 3.062 in Open End Width, 5/8 in Open End Thickness, 2.187 in Box End Width, 0.906 in Box End Thickness, Specifications Met: ASME B107.6-1994, High Alloy Steel, Black Oxide

• Features

• Box ends incorporate a radius corner design that engages the flats of the fastener, not the corners, providing up to 15 to 20% more torque while reducing fastener rounding, enhancing the turning of worn fasteners
• Box ends are offset a true 15 deg for clearing obstructions and knuckle clearance on flat surfaces
• The shank to box end transition area is also reinforced to provide greater strength
• Open end has a radius design for greater strength, especially when compared to a hex open end
• Large size stamp on both sides of the wrench for ease in identification
• Black oxide finish provides smooth edges with an industrial finish
• Manufactured from high alloy steel using the most up-to-date manufacturing process and heat treat for greater strength and durability

Specifications

Additional Information

Documents

• Catalog
