HARRINGTON HARR LX003-10

HARRINGTON LX003-10 Mini Lever Chain Hoist, 0.25 ton Load, 10 ft H Lifting, 40 lb Rated, 11 ft L Chain, 51/64 in Hook Opening

Invoice description: Hoist Mini Lever 1/4t Ch Ain 10' Lift

UNSPSC: 24101602
Manufacturer PN: LX003-10
$456.62 EA
Factory Order
Estimated to ship in 28 days
QTY:


HARRINGTON Lever Chain Hoist, Mini, Series: LX Series, 0.25 ton Load, 10 ft Lifting Height, 8 in Minimum Between Hooks, 51/64 in Hook Opening, 40 lb Pull to Lift, 5-29/32 in Lever Length, 11 ft Chain Length, Nickel Plated Chain, 1 Reeving, Weston Brake, Manual Handle

  • Features

  • Durable die-cast aluminum body with steel frame is compact and light weight
  • Very low headroom design for use in tight spaces
  • Free-chain mechanism allows for quick adjustments
  • Extremely low pulling force is required for operation
  • Weston-style brake is totally enclosed to protect against dirt, dust and rain
  • Single step reduction gear assures load holding performance
  • Load chain guide mechanism permits smooth and quiet guiding of chain
  • Rubber handle grip for ease of use
  • Effortless to transport, install and store
  • Electrostatic ename

Specifications

Brake TypeWeston
Chain Length11 ft
Chain MaterialNickel Plated
Handle TypeManual
Hook Opening51/64 in
Lever Length5-29/32 in
Lifting Height10 ft
Load Capacity0.25 ton
Minimum Between Hooks8 in
Pull to Lift Rated Load40 lb
Reeving1
SeriesLX Series
TypeMini

Additional Information

IncludesSafety Latch Hooks
Standards/ApprovalANSI/ASME B30.21
Country of OriginJP
