GARR GARR 79607
GARR 79607 220RA Center Cutting Single End Standard Length End Mill, 3/32 in Dia Cutter, 0.01 in Corner Radius, 3/8 in Length of Cut, 2 Flutes, 1/8 in Dia Shank, 1-1/2 in OAL, TiAlN Coated
Invoice description:
Em 3/32x3/8locx1/8x1-1/2 Cr0.01 2fl Tialn
Factory Order
GARR End Mill, Center Cutting Single End Standard Length, Series: 220RA, 3/32 in Diameter Cutter, 0.01 in Corner Radius, 1-1/2 in Overall Length, 3/8 in Length of Cut, 2 Flutes, Spiral Flute, 1/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Plain/Round Shank, 1-1/8 in Shank Length, Submicron Grain Solid Carbide, TiAlN Coated
Features
- Up to 40% faster than uncoated
- For stronger corners and part radius
- Extremely versatile
- Radius tolerance +/-0.001 in (+/-0.025 mm)
Specifications
ApplicationDry or Semi-Dry Machining
Corner Radius0.01 in
Cutter Diameter3/32 in
Cutting DirectionRight Hand
FinishTiAlN Coated
Flute TypeSpiral
Helix Angle30 deg
Length of Cut3/8 in
MaterialSubmicron Grain Solid Carbide
Number of Flutes2
Overall Length1-1/2 in
Series220RA
Shank Diameter1/8 in
Shank Length1-1/8 in
Shank TypePlain/Round
TypeCenter Cutting Single End Standard Length
Additional Information
Country of OriginUS
Specification Sheet
