GARR GARR 77710
GARR 77710 1520 General Purpose Stub Length Drill, V Drill - Letter, 0.377 in Drill - Decimal Inch, Submicron Grain Solid Carbide, Bright
Invoice description:
Drill Stub V (0.377) Crb Gp 135 Brt 3xd
Factory Order
GARR Stub Length Drill, General Purpose, Series: 1520, Imperial, V Drill - Letter, 0.377 in Drill - Decimal Inch, 3-1/4 in Overall Length, 3XD Cutting Depth, 2 Flutes, Right Spiral Flute, 1-7/8 in Flute Length, 0.377 in Shank, 135 deg Point, 4-Facet/Self-Centering Point, Right Hand Cutting Direction, Submicron Grain Solid Carbide Cutting Edge, Submicron Grain Solid Carbide, Bright, Applicable Materials: Mild Steel, Stainless Steel Alloy and Titanium Alloy
Features
- No spotting required in most applications
- Live tooling recommended on lathe processes
- 25 deg helix angle
Specifications
ApplicationGeneral Purpose
Applicable MaterialsMild Steel, Stainless Steel Alloy and Titanium Alloy
Cutting Depth3XD
Cutting DirectionRight Hand
Cutting Edge MaterialSubmicron Grain Solid Carbide
Drill Diameter Measurement SystemImperial
Drill Size - Decimal Inch0.377 in
Drill Size - LetterV
FinishBright
Flute Length1-7/8 in
Flute TypeRight Spiral
MaterialSubmicron Grain Solid Carbide
Number of Flutes2
Overall Length3-1/4 in
Point Angle135 deg
Point Type4-Facet/Self-Centering
Series1520
Shank Size0.377 in
TypeGeneral Purpose
Additional Information
Country of OriginUS
Specification Sheet
