Dormer UTD 0050903

Dormer 5972294 A920 Heavy Duty Premium Screw Machine Drill, 3.3 mm Drill - Metric, 0.1299 in Drill - Decimal Inch, HSS-E, Bright

UNSPSC:

Manufacturer PN: 5972294

^$7.66 EA

Factory Order
Estimated to ship in 14 days

enlarge

Product Overview

Dormer Screw Machine Drill, Heavy Duty Premium, Series: A920, Metric/Imperial, 3.3 mm Drill - Metric, 0.1299 in Drill - Decimal Inch, 49 mm Overall Length, 3XD Cutting Depth, 2 Flutes, Parabolic Flute, 18 mm Flute Length, Straight Shank, 130 deg Point, PFX Point, Right Hand Cutting Direction, HSS-E Cutting Edge, HSS-E, Bright, Applicable Materials: Magnetic Soft Steel, Structural Steel/Case Carburizing Steel, Plain Carbon Steel, Alloy steel/Hardened and Tempered Steel, Free Machining Stainless Steel, Austenitic, Ferritic + Austenitic, Martensitic, Lamellar Graphite, Nodular Graphite/Malleable Cast Iron, Titanium Unalloyed, Titanium Alloyed, Nickel Unalloyed, Nickel Alloyed, Copper, Bronze, Brass, High Strength Bronze, Aluminum Magnesium Unalloyed, Aluminum Alloyed, Thermoplastics and Thermosetting Plastics

Features
Heavy duty parabolic flute design allows greater drilling depths in one pass
Notched point improves chip formation
Premium cobalt base material increases wear resistance
Bright finish improves chip flow in soft or non-ferrous materials

Specifications

ApplicationFor advanced chip removal application

Applicable MaterialsMagnetic Soft Steel, Structural Steel/Case Carburizing Steel, Plain Carbon Steel, Alloy steel/Hardened and Tempered Steel, Free Machining Stainless Steel, Austenitic, Ferritic + Austenitic, Martensitic, Lamellar Graphite, Nodular Graphite/Malleable Cast Iron, Titanium Unalloyed, Titanium Alloyed, Nickel Unalloyed, Nickel Alloyed, Copper, Bronze, Brass, High Strength Bronze, Aluminum Magnesium Unalloyed, Aluminum Alloyed, Thermoplastics and Thermosetting Plastics

Cutting Depth3XD

Cutting DirectionRight Hand

Cutting Edge MaterialHSS-E

Drill Diameter Measurement SystemMetric/Imperial

Drill Size - Decimal Inch0.1299 in

Drill Size - Metric3.3 mm

FinishBright

Flute Length18 mm

Flute TypeParabolic

MaterialHSS-E

Number of Flutes2

Overall Length49 mm
